Special features:
item products are based on different modular dimensions and their associated system grooves.
Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.
The profiles in Line X feature a Line 8 system groove but have a particularly flat surface with
minimum curve radii that make them ideal for building sealed constructions.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.
EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.
These include batteries, etc.
All substances are registered according to the REACH regulation.
REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that users
have accurate information on the type and properties of operating materials, lubricants, etc.
that they might come into contact with.
Attributes
Line
line 8
Material
Al
Delivery unit
1 pce.
Weight
m =
2.01
kg
Details
Accessoires / Service
Hexagon Socket Head Cap Screw DIN 912 M8x25, bright zinc-plated
Delivery unit
1 pce.
1 pce.
Article-No.
0.0.610.71
0.0.610.71
Hexagon Socket Head Cap Screw DIN 912 M8x30, bright zinc-plated
Delivery unit
1 pce.
1 pce.
Article-No.
8.0.009.25
8.0.009.25
T-Slot Nut V 8 St M8, bright zinc-plated
Delivery unit
1 pce.
1 pce.
Article-No.
0.0.480.48
0.0.480.48
Downloads
Technical documentation(1 MB)
Classifications
Classifications are industry-wide product data standards that are used, among other things, to support structured processing in ERP and e-business systems. Do you need the classification data for all item products for your e-procurement system? If so, please don’t hesitate to contact us.
eCl@ss 11.0
23360291
eCl@ss 4.0
22041424
eCl@ss 4.1
22041424
eCl@ss 5.0
23250311
eCl@ss 5.1
23250311
eCl@ss 6.0.1
23250311
eCl@ss 7.1
23360290
eCl@ss 8.0
23360290
UNSPSC 7.0
31162503
UNSPSC 9.0
31162503
customs tariff number
76169990
