Special features:
item products are based on different modular dimensions and their associated system grooves.
Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.
The profiles in Line X feature a Line 8 system groove but have a particularly flat surface with
minimum curve radii that make them ideal for building sealed constructions.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.
EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.
These include batteries, etc.
All substances are registered according to the REACH regulation.
REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that users
have accurate information on the type and properties of operating materials, lubricants, etc.
that they might come into contact with.
Attributes
Line
line 8
Delivery unit
1 set
Weight
m =
225
g
ESD-safe
No
Details
Hinge Leaf, Al, anodized, natural
2 Locating lugs, Al, anodized, natural
2 Button-Head Screws ISO 7380-M8x18, St, bright zinc-pl.
2 Washers DIN 433-8.4, St, bright zinc-plated
2 T-Slot Nuts V 8 St M8, St, bright zinc-plated
Caps, PA-GF, grey
2 Locating lugs, Al, anodized, natural
2 Button-Head Screws ISO 7380-M8x18, St, bright zinc-pl.
2 Washers DIN 433-8.4, St, bright zinc-plated
2 T-Slot Nuts V 8 St M8, St, bright zinc-plated
Caps, PA-GF, grey
Accessoires / Service
Hinge Pin D8x51
Delivery unit
1 set
1 set
Article-No.
0.0.483.62
0.0.483.62
Hinge Pin D8x76
Delivery unit
1 set
1 set
Article-No.
0.0.483.61
0.0.483.61
Hinge Pin D8x116
Delivery unit
1 set
1 set
Article-No.
0.0.486.16
0.0.486.16
Classifications
Classifications are industry-wide product data standards that are used, among other things, to support structured processing in ERP and e-business systems. Do you need the classification data for all item products for your e-procurement system? If so, please don’t hesitate to contact us.
eCl@ss 11.0
23250304
eCl@ss 4.0
22041403
eCl@ss 4.1
22041403
eCl@ss 5.0
23250304
eCl@ss 5.1
23250304
eCl@ss 6.0.1
23250304
eCl@ss 7.1
23250304
eCl@ss 8.0
23250304
UNSPSC 7.0
31162403
UNSPSC 9.0
31162403
customs tariff number
76169990
