Special features:
item products are based on different modular dimensions and their associated system grooves.
Profiles from Lines 5, 6, 8, 10 and 12 each need corresponding sizes of fasteners.
The profiles in Line X feature a Line 8 system groove but have a particularly flat surface with
minimum curve radii that make them ideal for building sealed constructions.
Components that are RoHS-compliant contain no dangerous substances such as lead or cadmium.
EC Directive 2002/95/EC (RoHS 1) restricts the use of certain substances in electronic devices and components.
These include batteries, etc.
All substances are registered according to the REACH regulation.
REACH (Registration, Evaluation, Authorisation and Restriction of Chemicals) ensures that users
have accurate information on the type and properties of operating materials, lubricants, etc.
that they might come into contact with.
Attributes
Line
Line D30
Delivery unit
1 set
Weight
m =
81
g
ESD-safe
No
Details
Clamp-Profile D30 Hinge, Al, anodized, natural
Hinge Leaves, Al, anodized, natural
Countersunk Screw DIN 7991 M6x14, St, bright zinc-plated
Hexagon Socket Head Cap Screw DIN 6912 M6x12, St, bright zinc-plated
Hinge Al light, Pin Set D6
Notes on Use and Installation
Hinge Leaves, Al, anodized, natural
Countersunk Screw DIN 7991 M6x14, St, bright zinc-plated
Hexagon Socket Head Cap Screw DIN 6912 M6x12, St, bright zinc-plated
Hinge Al light, Pin Set D6
Notes on Use and Installation
Accessoires / Service
Profile Tube D30 heavy duty, natural
Delivery unit
cut-off max. 6000 mm
cut-off max. 6000 mm
Article-No.
0.0.642.34
0.0.642.34
Profile Tube D30-45° heavy duty, natural
Delivery unit
cut-off max. 6000 mm
cut-off max. 6000 mm
Article-No.
0.0.683.34
0.0.683.34
Key with T-Handle 4 A/F
Delivery unit
1 pce.
1 pce.
Article-No.
0.0.406.39
0.0.406.39
Rebate Strip D30 H13, grey similar to RAL 7042
Delivery unit
1 pce., length 2010 mm
1 pce., length 2010 mm
Article-No.
0.0.702.52
0.0.702.52
Magnetic Catch 32x10x5 sa
Delivery unit
1 set
1 set
Article-No.
0.0.710.66
0.0.710.66
Hinge D30-85 PP
Delivery unit
1 set
1 set
Article-No.
0.0.699.84
0.0.699.84
Classifications
Classifications are industry-wide product data standards that are used, among other things, to support structured processing in ERP and e-business systems. Do you need the classification data for all item products for your e-procurement system? If so, please don’t hesitate to contact us.
eCl@ss 11.0
23250304
eCl@ss 4.0
22041403
eCl@ss 4.1
22041403
eCl@ss 5.0
23250304
eCl@ss 5.1
23250304
eCl@ss 6.0.1
23250304
eCl@ss 7.1
23250304
eCl@ss 8.0
23250304
UNSPSC 7.0
31162403
UNSPSC 9.0
31162403
customs tariff number
83021000
